Victor Nickel Alloys stands out as a leading manufacturer and supplier of **Duplex Steel S32205 Sheet and Plates** in Abuja, Nigeria. They pride themselves on delivering top-notch products that are built for strength, corrosion resistance, and reliability. Crafted from high-quality raw materials and utilizing cutting-edge manufacturing techniques, these sheets and plates adhere to global standards. Renowned for their impressive mechanical strength and remarkable resistance to pitting, crevice, and stress corrosion, **Duplex Steel S32205 Sheet and Plates** are perfect for industries like oil and gas, chemical processing, desalination, and marine engineering, where performance and durability are non-negotiable.
Specifications : ASTM A240 / ASME SA240
Dimensions : ASTM, ASME, and API
Width : 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Thickness : 4mm-100mm
Length : 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface Finish : 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, chequered, embossed, hairline, sand blast, Brush, etching, Hot rolled plate (HR), Cold rolled sheet (CR), SATIN (Met with Plastic Coated) etc
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Form : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| Duplex 2205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
At Victor Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex S32205 Sheets and Plates in Abuja, Nigeria, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Nigeria, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
You’ll find **Duplex Steel S32205 Sheet and Plates** commonly used in **oil and gas pipelines, chemical processing equipment, pressure vessels, heat exchangers, and desalination plants**. They also play a vital role in **marine industries, structural frameworks, and pulp and paper production**, where exceptional strength and corrosion resistance are crucial. Thanks to their outstanding performance in tough environments, these sheets and plates are the go-to choice for **offshore structures, flue gas scrubbers, and power generation systems**, ensuring long-lasting reliability and lower maintenance costs.
