Nestled in the heart of Nigeria’s capital, Victor Nickelloys stands as your trusted partner for high-performance nickel alloys. We are proud to supply Haynes 230 sheets and plates to industries across Abuja and beyond, providing material solutions that excel under extreme conditions. Our commitment is to ensure that your critical projects are supported by top-tier materials and reliable service, right here where you need it.
Haynes 230 is a nickel-chromium-tungsten-molybdenum alloy renowned for its exceptional strength and outstanding stability at temperatures up to 2100°F (1150°C). It offers excellent resistance to oxidation and has good fabrication characteristics. This combination of high mechanical properties and thermal stability makes it a superior choice for demanding environments where other alloys might fall short.
| Specification : | AMS 5878 |
| Standard : | AMS, AMS, API |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Size : | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Haynes 230 (UNS N06230) |
| Weight% | C | Mn | Si | P | S | Cr | Co | Fe | Al | Ti | B | Cu | La | W | Mo | Ni |
| Haynes 230 | 0.05-0.15 | 0.30-1.0 | 0.25-0.75 | 0.03 | 0.015 | 20.0-24.0 | 5.0 | 3.0 | 0.20-0.50 | 0.10 | 0.015 | 0.50 | 0.005-0.05 | 13.0-15.0 | 1.0-3.0 | Rem |
| Material | Test Temp °F | Ultimate Tensile Strength | 0.2 % Yield Strength | Elongation in % | Hardness HB |
| Haynes Alloy 230 Extruded Bar Solution Treated (AMS 5891) | RT | 758 Mpa 110 ksi | 310 Mpa 45 ksi | 35 | 241 max |
At Victor Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Sheets and Plates in Abuja, Nigeria, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Nigeria, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
You’ll find Haynes 230 playing a vital role in the aerospace and industrial sectors, particularly within turbine engines, combustion chambers, and transition ducts. Its ability to maintain integrity under intense heat makes it ideal for critical components in power generation and chemical processing. Essentially, wherever extreme temperatures and corrosive conditions are the norm, Haynes 230 provides the reliable performance needed to keep operations running smoothly and safely.
