Welcome to Victor Nickelalloys, your trusted partner for high-performance materials right here in Abuja. We specialize in supplying and manufacturing premium Inconel 601 sheet and plates, providing local industries with direct access to world-class nickel-chromium alloys. Our commitment is to support Nigeria’s growing industrial sector with materials that offer exceptional durability and resistance, ensuring your projects are built to last and perform under the most demanding conditions.
The strength of Inconel 601 comes from its sophisticated composition, primarily nickel with significant chromium and aluminum content. This blend gives the material excellent mechanical properties, including high tensile strength and outstanding resistance to creep and stress rupture, even at elevated temperatures. It maintains its structural integrity and resists oxidation exceptionally well, making it a reliably robust choice for challenging environments.
| 601 Sheets & Plates Specifications | ASTM B168 / ASME SB168, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 601 Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Alloy 601 Sheets & Plates Size Range | Cold rolled ASME SB168 Grade 601 Inconel Sheet 0.5-6.4 mm Hot rolled ASME SB168 Grade 601 Inconel Sheet 3.0–10.0 mm |
| 601 Inconel Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Inconel 601 Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Inconel 601 Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Inconel 601 Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Inconel 601 Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SB168 601 Inconel Strips EN 10088 SA -240-601 Strips |
| Finish of Inconel 601 Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Inconel 601 Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.00 max | 0.50 max | 0.015max | 1.00 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Victor Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Sheets and Plates in Abuja, Nigeria, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Nigeria, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
You’ll find Inconel 601 sheets and plates are indispensable in sectors where failure is not an option. They are commonly used in furnace components, heat treatment equipment, and industrial heating systems. The aerospace and power generation industries also rely on them for critical parts like thermal baffles and combustors. Their excellent resistance to corrosion makes them equally valuable in chemical processing, ensuring long service life and operational safety where other materials would quickly degrade.
