Victor Nickelalloys is a well-respected manufacturer and supplier located in Abuja, Nigeria, specializing in top-notch Manganese Bronze Sheets and Plates. These products are celebrated for their remarkable strength, resistance to corrosion, and ease of machining. Crafted from a high-performance copper-zinc alloy enriched with manganese, iron, and aluminum, they offer outstanding durability and wear resistance. At Victor Nickelalloys, precision manufacturing and adherence to international quality standards are paramount, ensuring that their products perform reliably in demanding heavy-duty and marine settings. Manganese Bronze Sheets and Plates are perfect for industrial applications that require toughness, load-bearing capabilities, and resistance to seawater corrosion.
These sheets and plates primarily consist of copper (around 60%), zinc (up to 35%), manganese (about 3.5%), along with trace amounts of iron, aluminum, and tin. This unique blend gives them exceptional strength, hardness, and resistance to both corrosion and wear. In terms of mechanical properties, they boast a tensile strength of roughly 585 MPa, a yield strength of 275 MPa, and an elongation of 20%. Their excellent toughness and machinability make them ideal for components that operate under high loads and friction.
| Standard | JIS H3250-2006,ASTM B152M,GB/T2040-2008,ASTM B36,ASTM B194,ASTM B888, ASTM B19,ASTM B122,etc |
| Thickness | 0.1-120mm |
| Width | 2-2500mm |
| Length | 1m,2m,3m,6m,or as required |
| Surface | mill,polished,bright,mirror,hair line,brush,checkered,antique,sand blast,etc |
| Container size | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
| Application | Brass plate has a high corrosion resistance, and have good plasticity,in the air easy to cold and hot pressure processing,easy to welding, forging and tin, no stress corrosion cracking the tendency. |
| Cu(1) | Al | Fe | Pb | Mn | Sn | Zn | |
| Min./Max. | 57.0-60.0 | .25 | .8-2.0 | .20 | .05-.50 | .50-1.5 | Rem. |
| Nominal | 58.5 | – | 1.4 | – | .10 | 1.0 | 39.0 |
| ensile Strength, min | Yield Strength, at 0.5% extension under load, typ | Elongation, in 2 in. or 50 mm typ | Brinell Hardness (500 kg load) | Remarks | ||
|---|---|---|---|---|---|---|
| ksi | MPa | ksi | MPa | % | typical BHN | |
| 65 | 448 | 25 | 172 | 20 | 90 | |
Manganese Bronze Sheets and Plates are commonly found in marine hardware, propeller shafts, and pump components, thanks to their impressive resistance to seawater and brine corrosion. They’re also used in heavy-duty bearings, gears, valve parts, and hydraulic systems where strength and wear resistance are essential. Additionally, these plates are utilized in architectural fittings and industrial machinery. With their outstanding durability, machinability, and corrosion resistance, they are a trusted choice for high-performance mechanical and structural applications.
Contact us to get a quick quote for your requirement.
Manganese bronze sheets and plates are widely used in marine and industrial engineering due to their excellent strength, corrosion resistance and durability Typical applications include shipbuilding, where they are used for propeller shafts and fittings, and gears and engine components in the automotive industry will be those encountered in severe environments They are also ideal for machines that heavy duty parts, valves, pumps and marine components. In addition, manganese lead is used for electrical components and structural components requiring high strength and corrosion resistance.
