Victor Nickelalloys stands out as a top-notch manufacturer and supplier located in Abuja, Nigeria, with a focus on Monel 400 sheets and plates. Known for their remarkable resistance to corrosion and impressive mechanical strength, these products are designed to thrive in tough industrial settings. Catering to industries like marine, chemical, oil and gas, and aerospace, Victor Nickelalloys guarantees that each sheet and plate adheres to international quality standards. With an emphasis on precision, durability, and prompt delivery, their Monel 400 sheets and plates offer reliable solutions for structural, chemical, and high-stress applications throughout Nigeria and beyond.
The composition of Monel 400 sheets and plates includes around 63% nickel and 28–34% copper, along with trace amounts of iron, manganese, and silicon. This unique alloy blend provides outstanding resistance to corrosion from seawater, acids, and alkalis, while also ensuring high tensile strength, toughness, and fatigue resistance. These sheets and plates maintain stability across a broad temperature range, making them perfect for applications that require both chemical durability and mechanical performance in extreme conditions.
| Specifications | ASTM / ASME SB 127 |
|---|---|
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
| Thickness | 0.1mm to 12 mm Thk |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) |
| Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
|---|---|---|---|---|---|---|---|
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|---|
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
Victor Nickelalloys’ Monel 400 sheets and plates find extensive use in marine engineering, chemical processing equipment, desalination plants, oil and gas pipelines, and heat exchangers. They are particularly well-suited for structural components, flanges, and fabrication parts that come into contact with corrosive fluids or seawater. In the aerospace and defense sectors, Monel 400 sheets and plates are prized for their strength, durability, and long-lasting performance. Their blend of mechanical capabilities and corrosion resistance ensures dependable operation in industrial and marine environments across Nigeria and in global markets.
Contact us to get a quick quote for your requirement.
Monel 400 sheets and plates are widely used in marine, chemical, and aerospace industries due to their exceptional corrosion resistance and high strength. They are ideal for applications involving harsh environments, such as seawater and acidic conditions. Common uses include marine engineering components, chemical processing equipment, and aerospace structural parts. Their durability and resistance to oxidation and stress corrosion make them suitable for valves, pumps, and fittings in aggressive environments, ensuring long-term performance and reliability.
