Victor Nickelalloys is a reputable manufacturer and supplier located in Abuja, Nigeria, specializing in top-notch Monel ball valves. These valves are celebrated for their outstanding corrosion resistance, durability, and mechanical strength, making them reliable choices for tough industrial settings. Catering to industries like marine, chemical, oil and gas, and aerospace, Victor Nickelalloys guarantees that each Monel ball valve adheres to international quality standards. With a commitment to precision engineering, long-lasting performance, and prompt delivery, their products offer trustworthy flow control solutions for systems dealing with corrosive fluids, seawater, and high-pressure situations throughout Nigeria and beyond.
Monel ball valves are primarily crafted from Monel 400, an alloy that consists of about 63% nickel and 28–34% copper, along with trace amounts of iron, manganese, and silicon. This unique blend provides remarkable resistance to acids, alkalis, and seawater while ensuring high tensile strength, toughness, and corrosion resistance. Monel valves are incredibly durable, stable across a broad temperature range, and can endure extreme pressure conditions, making them perfect for critical industrial and marine applications.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Ni | Mn | C | Si | Cu | S | Fe | Cr |
| Monel 400 | 63.00 min | 2.00 max | 0.30 max | 0.50 max | 28.0-34.0 | 0.24max | 2.50 max | – |
| Element | Melting Point | Yield Strength (0.2%Offset) | Elongation | Density | Tensile Strength |
| Monel 400 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | 40 % | 8.8 g/cm3 | Psi – 80,000 , MPa – 550 |
Victor Nickelalloys’ Monel ball valves find extensive use in chemical processing plants, oil and gas pipelines, marine systems, desalination plants, and heat exchangers. They excel at regulating the flow of corrosive fluids in pipelines, pump systems, and offshore installations. With their combination of strength, corrosion resistance, and longevity, these valves ensure dependable operation in harsh environments, establishing Victor Nickelalloys as a preferred supplier of Monel ball valves in Nigeria and on the international stage.
Contact us to get a quick quote for your requirement.
Monel ball valves are used in various industrial applications where durability and corrosion resistance are essential. They are ideal for chemical processing, marine environments, and aerospace systems, offering reliable performance in harsh conditions. Their resistance to seawater and acidic substances makes them suitable for oil and gas industries. Additionally, Monel ball valves are employed in power generation and petrochemical facilities, ensuring effective control and longevity in high-pressure and extreme temperature applications.
