Victor Nickelalloys stands out as a reliable manufacturer and supplier of top-notch **Monel Needle Valves** in **Abuja, Nigeria**. We provide dependable solutions tailored for demanding industrial applications. Crafted from high-quality Monel alloys, these valves boast impressive corrosion resistance, remarkable strength, and durability, even in the toughest environments. Thanks to our state-of-the-art manufacturing facilities and rigorous quality control processes, Victor Nickelalloys ensures that our precision-engineered Monel Needle Valves are perfect for critical flow control tasks. Designed to excel under high pressure and temperature, they are the go-to choice for industries like oil and gas, chemical processing, marine, and power generation.
Monel Needle Valves are mainly made up of **nickel (about 63%) and copper (roughly 28–34%)**, along with trace amounts of **iron, manganese, carbon, and silicon**. This unique blend gives them outstanding resistance to acids, alkalis, and seawater corrosion. On the mechanical side, they showcase **high tensile strength (550–620 MPa)**, solid yield strength, and impressive hardness. The exceptional ductility and toughness of Monel make these valves perfect for extreme conditions, ensuring they maintain their strength and performance across a broad temperature range. Their combination of corrosion resistance and mechanical durability guarantees long-lasting reliability in critical applications.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Ni | Mn | C | Si | Cu | S | Fe | Cr |
| Monel 400 | 63.00 min | 2.00 max | 0.30 max | 0.50 max | 28.0-34.0 | 0.24max | 2.50 max | – |
| Element | Melting Point | Yield Strength (0.2%Offset) | Elongation | Density | Tensile Strength |
| Monel 400 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | 40 % | 8.8 g/cm3 | Psi – 80,000 , MPa – 550 |
At Victor Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Needle Valve in Abuja, Nigeria, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Nigeria, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel Needle Valves find their place in various sectors, including **chemical processing, oil and gas refineries, marine engineering, and power generation systems**. Their excellent corrosion resistance and precise flow control capabilities make them ideal for managing **acidic, alkaline, and saline fluids**, especially in **offshore and seawater systems**. Additionally, these valves are utilized in **pharmaceutical, petrochemical, and instrumentation applications**, where accurate fluid metering and leak-free operation are crucial. Their robust design and resistance to oxidation at high temperatures further enhance their appeal in demanding environments.
