Victor Nickelalloys is a top manufacturer and supplier located in Abuja, Nigeria, specializing in high-quality Nickel Alloy 201 Sheets and Plates. The company aims at providing products that comply with world standards in terms of their performance, strength, and corrosion resistance. By incorporating very modern manufacturing processes and strict quality control, Victor Nickelalloys is able to maintain the excellent durability and reliability of their sheets and plates. The company’s Nickel Alloy 201 Sheets and Plates are the most reliable ones in different industries like chemical processing, marine, oil and gas as well as power generation to name a few. They can withstand extreme and corrosive environments while providing the best service.
Nickel Alloy 201 Sheets and Plates mainly contain one of the most commercially pure nickel (approximately 99.6%) with small amounts of carbon, copper, iron, and silicon. The given composition assures the first of the most important features of the material, resistance to corrosion, oxidation, and reducing chemicals. Along with this, the material provides excellent mechanical properties such as high tensile strength, great ductility, and thermal conductivity. At the same time, Nickel Alloy 201 is capable of keeping its structural framework both at extremely high as well as low temperatures, thus it is able to provide lasting performance under industrial and environmental conditions and away from demand heavy scenarios.
| Nickel Alloy Sheets & Plates Specifications | ASTM B162 / ASME SB162, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| Nickel Alloy Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Nickel Alloy Sheets & Plates Size Range | Cold rolled ASME SB162 Grade 201 Nickel Alloy Sheet 0.5-6.4 mm Hot rolled ASME SB162 Grade 200 Nickel Alloy Sheet 3.0–10.0 mm |
| Nickel Alloy Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Nickel Alloy Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Nickel Alloy Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Nickel Alloy Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Nickel Alloy Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SB162 200 Nickel Alloy Strips EN 10088 SA -240-400 Strips |
| Finish of Nickel Alloy Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Nickel Alloy Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Element | Ni+Co | Cu | Si | Mn | C | Mg | S | P | Fe |
|---|---|---|---|---|---|---|---|---|---|
| Nickel | 99.99 | 0.015 | 0.03 | 0.002 | 0.01 | 0.01 | 0.001 | 0.001 | 0.04 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
At Victor Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy 201 Sheet and Plates in Abuja, Nigeria, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Nigeria, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
The applications and uses of Nickel Alloy 201 Sheets and Plates can only be found in witnessing their dependability in industries such as corrosion-resistant ones and the like where thermal stability would be essential, etc. Next they are perfect for the likes of chemical processing, marine engineering, food production or even power generation, to mention but a few. These sheets and plates serve as common materials that are employed in the fabrication of heat exchangers, pressure vessels, evaporators, and storage tanks that deal with caustic alkalis and acidic solutions. Their problem-free resistance to oxidation and their high thermal conductivity property make them quite worthy of using them at extremely high-temperature sites as opposed to low-temperature ones thus they retain the features of lasting, safe, and reliable industrial staff work.
