Victor Nickelalloys is a reputable manufacturer and supplier located in Abuja, Nigeria, specializing in top-notch Nitronic Sheets and Plates. These products are known for their impressive strength, resistance to corrosion, and remarkable toughness. The stainless steel alloys feature nitrogen as a key strengthening element, which gives them an edge in mechanical performance over standard austenitic grades. At Victor Nickelalloys, we take pride in crafting Nitronic Sheets and Plates with precision and a smooth surface finish, ensuring that our customers receive consistent quality and reliability. These sheets and plates are perfect for challenging environments like marine, chemical processing, and architectural applications, where strength and corrosion resistance are crucial.
The composition of Nitronic Sheets and Plates primarily includes chromium (16–18%), nickel (4–8%), manganese (5–9%), and nitrogen, along with trace amounts of molybdenum and silicon depending on the specific grade (like Nitronic 50 or Nitronic 60). The addition of nitrogen boosts mechanical strength without sacrificing ductility or toughness. These alloys showcase high yield strength—nearly double that of 304 and 316 stainless steels—and they maintain excellent oxidation and wear resistance, even at elevated temperatures. Plus, they retain non-magnetic properties in both annealed and cold-worked states.
| Standard : | UNS S21906 | AMS 5656 | MIL-T-9821 | ASTM A276 | ASME SA276 UNS S21800 | Alloy 218 | ASME SA 193 | AMS 5848 | ASTM A 193 EN 1.3964 | ISO 15156-3 | NACE MR0175 | UNS S20910 | AMS 5764 | ASTM A193 | Werkstoff 1.3964 |
| Size : | 20mm x 1200 x 500 |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Nitronic 40 / 50 / 60 (UNS-S20910, S21800, S21900) |
| STANDARD | UNS | EN | ISO | NACE | AMS | ASTM | Werkstoff | other |
| Nitronic 40 | S21906 | – | – | – | 5656 | A276 | – | MIL-T-9821 |
| Nitronic 50 | S20910 | 1.3964 | 15156-3 | MR0175 | 5656 | A193 | 1.3964 | MIL-T-9821 |
| Nitronic 60 | S21800 | – | – | – | 5848 | A193 | 1.3964 | Alloy 218 |
| Weight% | C | P | Si | Ni | Fe | Mn | S | Cr | N | Mo | Cu |
| Nitronic 40 (21-6-9) | 0.04 max | 0.060 max | 1.00 max | 5.5-7.5 | Bal | 8-10 | 0.030 max | 19-21.5 | 0.15-0.40 | 0.75 max | 0.75 max |
| Alloy | Cross Section Size | Test Direction | Yield Strength 0.2% | Ultimate Tensile Strength | Elongation in 2″(%) | Reduction of Area % | Rockwell B Hardness | ||
| ksi | MPa | ksi | MPa | ||||||
| Nitronic 40 (21-6-9) | 6″ (152mm) sq | Longitudinal | 62 | 428 | 95 | 655 | 46 | 69 | |
| Nitronic 40 (21-6-9) | 6″ (152mm) sq | Transverse | 52 | 358 | 93 | 641 | 30 | 45 | |
| Nitronic 40 (21-6-9) | 4″ (102mm) sq | Longitudinal | 56 | 386 | 97 | 668 | 53 | 73 | |
| Nitronic 40 (21-6-9) | 1″ (25.4mm)sq | Longitudinal | 52 | 358 | 101 | 696 | 53 | 73 | 90 |
At Victor Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nitronic Sheet and Plates in Abuja, Nigeria, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Nigeria, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nitronic Sheets and Plates are widely utilized in scenarios where a blend of strength, corrosion resistance, and wear performance is essential. You’ll find them in marine hardware, pump shafts, valves, fasteners, pressure vessels, and heat exchangers. In the chemical and petrochemical sectors, Nitronic alloys stand up to corrosive and chloride-rich environments with reliability. Their outstanding galling resistance makes them ideal for moving parts like couplings and shafts. With Nitronic Sheets and Plates, you can expect a long service life, minimal maintenance, and exceptional performance in high-stress, corrosive, and high-temperature applications.
