Victor Nickelalloys stands out as a premier manufacturer and supplier located in Abuja, Nigeria, specializing in high-quality Rene 41 Foil. This foil is celebrated for its remarkable strength, resistance to oxidation, and impressive performance at high temperatures. Crafted from a top-tier nickel-based superalloy, it’s engineered to uphold its structural integrity and mechanical properties even in the most extreme thermal and stress conditions. At Victor Nickelalloys, they prioritize precise thickness control, a smooth surface finish, and exceptional metallurgical consistency. Rene 41 Foil is perfect for applications in aerospace, gas turbines, and high-temperature industrial settings where reliability and durability are crucial.
The composition of Rene 41 Foil is primarily nickel (about 55%), along with chromium (19%), cobalt (11%), molybdenum (10%), and trace amounts of titanium and aluminum that enhance its precipitation hardening. This alloy boasts outstanding tensile and creep strength up to 980°C, along with excellent resistance to oxidation and corrosion. It retains superior hardness, thermal stability, and fatigue strength, even in harsh oxidizing and high-stress environments. Thanks to its fine microstructure and carefully controlled alloy composition, it offers excellent formability, weldability, and resistance to scaling, making it ideal for precision-engineered components.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
At Victor Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Abuja, Nigeria, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Nigeria, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
| Grade | UNS | Workstoff | AMS | GE |
| Rene 41 | N07041 | 2.4973 | AMS 5545, AMS 5712, AMS 5713, AMS 5800 | GE B50TF109, GE B50TF76 |
Rene 41 Foil finds extensive use in industries that require high performance at elevated temperatures. In the aerospace field, it’s utilized in turbine engine components, exhaust systems, and afterburner liners. In the power generation and chemical processing sectors, it serves as heat shields, high-temperature seals, and combustion liners. The foil’s exceptional oxidation and creep resistance make it a top choice for applications that experience cyclic thermal exposure. With its durability, stability, and strength under extreme conditions, Rene 41 Foil is an outstanding option for critical and high-stress environments.
