Home > Rene 41 Sheets and Plates
Victor Nickelalloys is a well-respected manufacturer and supplier located in Abuja, Nigeria, with a focus on high-performance **Rene 41 Sheets and Plates**. The company prides itself on its dedication to quality, precision, and innovation, offering top-notch materials designed for extreme environments. Rene 41 is a nickel-based superalloy celebrated for its remarkable strength, resistance to oxidation, and stability at high temperatures. Victor Nickelalloys guarantees that every sheet and plate adheres to international standards, making them perfect for demanding applications in aerospace, power generation, and chemical processing industries that require exceptional mechanical and thermal performance.
The composition of Rene 41 Sheets and Plates primarily includes **nickel, chromium, cobalt, molybdenum, titanium, and aluminum**, along with trace elements that boost corrosion resistance and strength. These materials showcase impressive **mechanical properties**, such as high tensile strength, creep resistance, and oxidation resistance up to 980°C. The alloy remains stable even under prolonged exposure to high temperatures and stress, making it an excellent choice for components that operate in harsh conditions where reliability and durability are essential.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
At Victor Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Abuja, Nigeria, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Nigeria, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Rene 41 Sheets and Plates find extensive use in **aerospace engines, gas turbines, jet exhaust components, and high-temperature fasteners** due to their exceptional heat and oxidation resistance. They are also employed in **chemical processing plants, nuclear reactors, and power generation systems**, where thermal stability and corrosion resistance are crucial. The alloy’s outstanding mechanical integrity makes it perfect for parts that endure high stress and heat, ensuring a long service life and consistent performance in the most challenging industrial and engineering applications.
