Victor Nickelalloys, a top-notch manufacturer and supplier located in Abuja, Nigeria, specializes in high-quality Super Duplex Manifold Valves that are built for outstanding performance, durability, and resistance to corrosion in tough industrial settings. Crafted from premium super duplex stainless steel, these valves are precision-engineered to deliver exceptional mechanical strength, ensuring leak-free operation and reliability even under extreme pressure and temperature conditions. With their remarkable resistance to pitting, crevice, and stress corrosion cracking, Super Duplex Manifold Valves from Victor Nickelalloys are perfect for use in the oil & gas, chemical, marine, and power generation sectors, where consistent flow control and corrosion resistance are essential.
These valves feature a dual-phase austenitic-ferritic microstructure, typically comprising 24–26% chromium, 6–8% nickel, 3–5% molybdenum, and trace amounts of nitrogen. This well-balanced composition provides excellent corrosion resistance in chloride-rich environments, along with superior strength and toughness. They boast a tensile strength of around 800–1000 MPa and a yield strength of about 550 MPa, ensuring they maintain their structural integrity even in high-pressure systems. Additionally, they offer great fatigue resistance, weldability, and durability, making them ideal for continuous operation in harsh and corrosive industrial conditions.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
At Victor Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Manifold Valve in Abuja, Nigeria, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Nigeria, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Manifold Valves from Victor Nickelalloys are extensively utilized in the oil and gas industry for managing and isolating fluid flow in offshore and subsea systems. In the chemical and petrochemical fields, they are used in process plants, heat exchangers, and reactors that handle corrosive chemicals. The marine and desalination industries rely on them for seawater treatment, pump systems, and piping networks due to their excellent resistance to chlorides. Furthermore, these valves are also applied in the pulp and paper, power generation, and pharmaceutical industries, where dependable pressure control and leak prevention are crucial.
