Victor Nickelalloys stands out as a top-notch manufacturer and supplier of premium **Titanium Tube Fittings** right from **Abuja, Nigeria**. Our fittings are crafted to deliver outstanding performance in tough industries where strength, resistance to corrosion, and reliability are non-negotiable. Built to comply with international standards, our Titanium Tube Fittings find their place in sectors like chemical processing, aerospace, marine, and power generation. We offer a wide array of fittings, including elbows, tees, adapters, and couplings, all designed to ensure leak-proof connections and durability, even in the harshest conditions. At Victor Nickelalloys, we are dedicated to providing top-quality products with unmatched precision and performance.
Our Titanium Tube Fittings are primarily made up of **titanium (about 90%)**, with small amounts of **aluminum, vanadium, iron, and oxygen** added to boost strength and corrosion resistance. They showcase remarkable mechanical properties, including **high tensile strength (up to 1000 MPa)**, **lightweight**, and **outstanding resistance to seawater and chemical corrosion**. These fittings maintain their mechanical integrity across a broad temperature range, offering excellent fatigue resistance, high toughness, and superb weldability, making them perfect for critical industrial and aerospace applications.
| Specifications (ASTM/ASME) | ASTM B381/381M R56400, ASME SB381/381M R56400 |
| Tube Size | 1/16 OD to 2 OD, Od to 50mm OD |
| Types we Offer | Titanium Instrumentation Fittings Ti Grade 5 Double Ferrule Fittings Ti Grade 2 Twin Ferrule Fittings Ti-6al-4v Eli Titanium Ferrule Fittings Pure Titanium Pneumatic Fittings Ti Grade 6 Flare Fittings Cp Gr2 Ti JIC Fittings Tial6v4 Instrumentation Fittings Ti Alloy Grade 5 Hydraulic Hose Fittings ASTM B348 Grade 5 Compression Fittings Cp Grade 1 Double Ferrule Fittings ASME SB 348 Grade 2 Push-To-Connect Fittings Grade 5 Compression Fittings Ti Gr2 Hydraulic Fittings |
| Material Grades | Titanium Gr.5 – UNS R56400, Titanium Gr 2 – UNS R50400 |
| THREAD | BSPT, UNF, BSP, NPT, ISO, SAE, etc. |
| Forms | Tube to Union, Tube to Male, Tube to Female, Instrument Pipe Fittings, Accessories |
| Working Pressure | Upto 2000 to 6000 PSI |
| Medium – Pressure Gaugeable | Pressure Ratings: Up to 20 000 psig (1378 bar) Temperature Ratings: Up to 1000°F (537°C) |
| High-Pressure | Pressure Ratings: Up to 60 000 psig (4134 bar) Temperature Ratings: Up to 1000°F (537°C) |
| Body Type | FORGED, BAR STOCK |
| PTFE Standards | ASTM D1710, ASTM D3294 |
| Surface | Export bright finish, short blasted finish, electroplated finish |
| Applications Temperature | 150-400°C |
| Ends | Welding, Threaded, JIC |
| Packing Details | As per your detailed request Normally carton size – 21*16*14CM/31*21*16CM/36*45*50CM Normally wooden box size – 38*27*17CM Normally 1piece/ opp, 10-20pcs/ carton |
| Element | Ti | C | Fe | H | N | O | Al | V |
| Titanium | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
At Victor Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Titanium Tube Fittings in Abuja, Nigeria, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Nigeria, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Titanium Tube Fittings are widely utilized in industries where reliability and corrosion resistance are paramount. They are particularly suited for **aerospace systems**, **chemical and petrochemical processing**, **offshore and marine engineering**, **power generation**, and **pharmaceutical equipment**. These fittings guarantee secure, leak-free connections in high-pressure and high-temperature environments. Thanks to their lightweight yet robust design, they are also favored in **heat exchangers**, **hydraulic lines**, and **desalination plants**. Their long lifespan and resistance to oxidation make them a smart, cost-effective choice for modern engineering.
